Customizable Movable Partition Wall Office Operable Wall Systems

Brand Name:	AE
Model Number:	AE65
MOQ:	10 Square Meter
Price:	USD 79-108 per square meter
Packaging Details:	foam layer and hard cardboard with plywood case or steel pallet
Payment Terms:	T/T, L/C, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO9001 SGS CANS

Series:

AE65 Movable Partition Wall

Finishing Option:

Customer-supplied Materials

Application:

Restaurant ,Meeting Room

Thickness:

STC Rating:

42-56dB

Dimensions:

Customization (Height: Up To 4.5M, Width Per Panel: Up To 1.2M)

Name:

Movable Partition Wall

Supply Ability:

1000 SQUARE METER PER MONTH

Highlight:

Customizable Movable Partition Wall

Product Description

Customizable Movable Partition Wall Office Operable Wall Systems

AE operable partitions are a series of panels suspended from tracks with high quality, functionality and variability for room-dividing and multifunctional layout configuration.

What we offer:

1) German Partition Technology Global Professional Space Solutions

2) Highly competitive prices

3) Good quality control

4) Smooth communication

5) state-of-art technology products

6) Effective OEM&ODM service

Roller Option & Feature:

1. Dupont POM roller

2. 304 stainless steel heavy duty roller with safety device & CNC machining

3. Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature

1. Thickness: 68mm & 89mm & 105mm

2. Wide variety of acoustical and decorative finishes available

3. 6061-T6 profile and inside Q235 steel frame for superior durability

4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m,

Specification:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
	Dimensions in mm*			Design
Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department. ** Depending on the sound insulation/weight

Customizable Movable Partition Wall Office Operable Wall Systems 0

Customizable Movable Partition Wall Office Operable Wall Systems 1

Customizable Movable Partition Wall Office Operable Wall Systems 2
