Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall

Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall

Brand Name: AE
Model Number: Panoramic system EGG-100C
MOQ: 10 Square Meter
Price: USD112-145Per Square Meter
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SQUARE METER PER MONTH
Detail Information
Place of Origin:
Guangdong, CHINA
Certification:
ISO9001 SGS
Material:
Melamine,wooden
Product Name:
Glass Partition Wall
Production Standard:
Basis On The Shop Drawings Which Approved By The Buyer
Profile Of Hanging Partition:
Aluminum Alloy, PVC Strip Sound Proof Partition Walls
Glass Of Hanging Partition:
Clear Tempered Glass, Frosted Glass, Acid Etched Glass
Design:
OEM & ODM
Sound Insulation:
30-42dB
Packaging Details:
foam layer and hard cardboard with plywood case
Highlight:

Sliding Office Glass Partition Wall

Product Description

Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall


Discover our high-quality aluminum frame sliding double glazed office glass partition walls, designed to enhance modern office environments with both style and functionality. These partition walls provide superior acoustic insulation and a sleek, contemporary look, ideal for creating flexible and private office spaces.


Description:

Experience the perfect blend of environmental sustainability and lightweight design with our advanced office glass partition systems.

Eco-Friendly and Lightweight: Our partitions are designed with environmentally friendly materials and lightweight components, making them a smart choice for modern, green office spaces.

Top Hung System: Enjoy a clean, unobtrusive design with our top hung system, eliminating the need for a floor track and providing a sleek, streamlined look.

Effortless Movement: Retractable top and bottom seals ensure smooth and easy operation of panels, enhancing the user experience.

Versatile Panel Profiles: Choose from concealed or exposed panel edge profiles to match your desired aesthetic.

Flexible Panel Stacking: Our system offers numerous panel stacking options, allowing for complete flexibility in configuring your office layout.

Wide Range of Finishes: Select from an extensive range of surface finishes that not only look great but also simplify construction and transportation.

Sound Reduction Options: The partition system provides various levels of sound reduction, catering to your acoustic needs and ensuring a quieter work environment.

Elegant and Robust: Combining elegance with durable construction, our partitions offer both style and strength for high-traffic areas.


Specification:



Technical characieristics

WALL THICKNESS
108mm/90mm
HEIGHT up to 3000mm
GRID WIDTH up to 1200mm
WEIGHT 70-80kg/sq.m
ATTACHMENT TO BUILDING STRUCTURE Concealed connections to the slab and walls; sealing along the perimeter; deviations ±10mm in height and width
GLASS THICKNESS 10mm/12mm tempered
VISIBILITY Transparent, coloured, matte glass; between-the-glass blinds; foil, screen printing, enamel
DESCRIPTION Glazed partition with an in-plane streamlined look. Made from aluminium, double-glazing structurally adhered to the profiles.



Project:



Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall 0Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall 1


Our Services:
Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall 2Dividers Aluminium Frame Sliding Double Glazed Office Glass Partition Wall 3
