Office Glass Partition Wall
Created with Pixso.

Double Glazed Full Height Glass Wall Partition for Contemporary Offices

Double Glazed Full Height Glass Wall Partition for Contemporary Offices

Brand Name: AE
Model Number: Panoramic system EGG-100
MOQ: 10 Square Meter
Price: USD77-99Per Square Meter
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SQUARE METER PER MONTH
Detail Information
Place of Origin:
Guangdong, CHINA
Certification:
ISO9001 SGS
Series:
Office Glass Partition Wall
Compliance:
Medical Industry,laboratory,workspace,gym
Wall Thickness:
100mm
Production Standard:
Basis On The Shop Drawings Which Approved By The Buyer
Surface Finishing And Color:
Black & White Powder Coating
Hardware:
High Quality, Made In Germany (ECO Brand)
Packaging Details:
foam layer and hard cardboard with plywood case
Highlight:

Double Glazed Glass Wall Partition

,

Full Height Glass Wall Partition

,

Contemporary Offices Glass Wall Partition

Product Description

Double Glazed Full Height Glass Wall Partition for Contemporary Offices



Upgrade your office environment with our Double Glazed Full Height Glass Wall Partition, perfect for contemporary spaces. This design offers superior sound insulation and energy efficiency, while the floor-to-ceiling glass panels create an open, airy atmosphere that aligns with modern office aesthetics.



Additional Features:

1) Integrated Blinds: Blinds can be installed within double-glazed partitions for adjustable privacy.

    Smart Glass Technology: Allows the glass to change from clear to opaque at the touch of a button.



2) Glass module :

Tempered Glass: Common thicknesses range from 8mm to 12mm, offering strength and safety.



2) Frame Material:

Aluminum Frame: Anodized or powder-coated, often 1.5mm to 2.3mm thick, available in various finishes such as silver, black, or white.

Frameless Option: For a sleek, minimalist appearance, using heavy-duty glass fittings.



3) Dimensions:

Height: Can range from standard 4 meters (13 feet) to full floor-to-ceiling installations, depending on the building's height.

Width: Customizable to fit the space; panels typically range from 1 meter (3.3 feet) to 3 meters (10 feet) wide.



4) Installation:

Fixed Installation: The panels are securely mounted to the floor and ceiling.

Modular Design: Allows for easy reconfiguration or relocation of the partitions.

Floor Track or Trackless: Depending on the design preference, partitions may include or exclude floor tracks for a cleaner look.



Specification:



Technical characieristics

WALL THICKNESS
108mm/90mm
HEIGHT up to 3000mm
GRID WIDTH up to 1200mm
WEIGHT 70-80kg/sq.m
ATTACHMENT TO BUILDING STRUCTURE Concealed connections to the slab and walls; sealing along the perimeter; deviations ±10mm in height and width
GLASS THICKNESS 10mm/12mm tempered
VISIBILITY Transparent, coloured, matte glass; between-the-glass blinds; foil, screen printing, enamel
DESCRIPTION Glazed partition with an in-plane streamlined look. Made from aluminium, double-glazing structurally adhered to the profiles.
