Collapsing Single Glazed Aluminium Frame Glass Wall Easy Installation

Brand Name:	AE
Model Number:	Panoramic system EGG-100C
MOQ:	10 Square Meter
Price:	USD69-92Per Square Meter
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 SQUARE METER PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, CHINA

Certification:

ISO9001 SGS

Product Name:

Aluminium Frame Glass Wall

Application:

Office , Hall .

Production Standard:

Basis On The Shop Drawings Which Approved By The Buyer

Profile Of Hanging Partition:

Aluminum Alloy, PVC Strip Sound Proof Partition Walls

Glass Of Hanging Partition:

Clear Tempered Glass, Frosted Glass, Acid Etched Glass

Design:

OEM & ODM

Sound Insulation:

30-42dB

Packaging Details:

foam layer and hard cardboard with plywood case

Highlight:

Collapsing Aluminium Frame Glass Wall

Single Glazed Aluminium Frame Glass Wall

Aluminium Frame Glass Wall Easy Installation

Product Description

Collapsing Aluminum Single glazed Office Glass Partition Wall Easy Installation

Introducing our innovative collapsing aluminum single-glazed office glass partition wall, designed for effortless installation and exceptional flexibility. This partition wall features a sleek aluminum frame combined with clear glass panels, creating a modern, open work environment that maximizes natural light. The collapsible design allows for quick reconfiguration, making it ideal for dynamic office spaces that require adaptability. Enjoy the ease of setup and the versatility of a system that can be tailored to your changing needs, all while maintaining a sophisticated and professional appearance. Transform your workspace with style and convenience.

Specification:

1> It doesn’t need track on the floor, we only hang the track on the ceilings and it can be at the same plane with the ceiling decoration. It won’t affect the whole decoration style;

2> Around the board ,there is sound insulation rubber, it can help to insulate the sound entering;

3> The operation ways is much easier, it’s better than the old ways which was use spring before;

4> We can add single or double doors on the board for convenience;

5> We have many different finish to meet customer different requirement and get different decoration effect.

Specification:

Technical characieristics
WALL THICKNESS	108mm/90mm
HEIGHT	up to 3000mm
GRID WIDTH	up to 1200mm
WEIGHT	70-80kg/sq.m
ATTACHMENT TO BUILDING STRUCTURE	Concealed connections to the slab and walls; sealing along the perimeter; deviations ±10mm in height and width
GLASS THICKNESS	10mm/12mm tempered
VISIBILITY	Transparent, coloured, matte glass; between-the-glass blinds; foil, screen printing, enamel
DESCRIPTION	Glazed partition with an in-plane streamlined look. Made from aluminium, double-glazing structurally adhered to the profiles.
