Top Suspension Aluminum Track Folding Partition Walls Glass Movable Wall

Brand Name:	AE
Model Number:	AE85
MOQ:	10 Square Meter
Price:	USD 90-110 Per Square Meter
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 SQUARE METER PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, CHINA

Certification:

ISO9001 SGS

Products:

Acoustic Folding Partition Walls Movable

Application:

Hospital, Hotel, Laboratory, Restaurant ,meeting Room, Shool

Material:

6061-T6 Aluminum Alloy Frame+ Galvanized Square Tube Keel

Finishing Option:

Fabric, Veneer, Murals And Even Customer-supplied Materials

Sound Insulation:

52DB

Function:

Operable, Fold-away, Suspending, Dividing, Soundproofing

Thickness:

89mm

Design:

Customized Style

Dimensions:

Customization (Height: Up To 4.5M, Width Per Panel: Up To 1.2M)

Base Board:

15mm MDF Magnesium Board, Plywood, Customer-supplied Materials

Packaging Details:

foam layer and hard cardboard with plywood case or steel pallet

Highlight:

Folding Partition Walls

Glass Movable Wall

Aluminum Track Folding Partition Walls

Product Description

Movable Acoustic Walls | Global Supplier of Office Partition Systems
AE Partitions: Space Optimization Experts
Next-generation soundproof dividers featuring:
◆ Aircraft-Grade Aluminum Frames
◆ Hydraulic-Magnetic Sealing Tech
◆ 24/7 Remote Project Monitoring
◆ 15% Higher Load Capacity vs Industry Standard
◆ LEED-Compliant Sustainable Designs

Choose AE Partition—where functionality meets elegance.

SPECIFICATION:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
	Dimensions in mm*			Design
Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department. ** Depending on the sound insulation/weight
