Movable Partition Wall with 800N Sealing Power and 40N/m Magnetic Attraction for Up to 4.5M Height

Brand Name:	AE
Model Number:	AE65
MOQ:	10 Square Meter
Price:	USD 79-108 per square meter
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	1000 SQUARE METER PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO9001 SGS CANS

Product:

Movable Partition Wall

Base Board:

Customer-supplied Materials

Compliance:

Meeting Room

Thickness:

68CM

STC Rating:

42-56dB

Dimensions:

Customization (Height: Up To 4.5M, Width Per Panel: Up To 1.2M)

Name:

Movable Partition Wall

Packaging Details:

foam layer and hard cardboard with plywood case or steel pallet

Highlight:

800N Sealing Power Movable Partition Wall

40N/m Magnetic Attraction Movable Partition Wall

Up to 4.5M Height Movable Partition Wall

Product Description

Movable Partition Walls for a Flexible Modern Office

With sound insulating operable partition walls you can divide larger spaces quickly into individual work areas, team spaces, meeting rooms, and educational environments without interruption.

Quality Service

Custom production following your design specifications
Quick turnaround on free quotes (1-6 business days depending on project size)
Comprehensive product specifications and value-engineered alternatives
Professional submittal drawings provided
Guaranteed on-time deliveries

Roller Options & Features

Dupont POM rollers for smooth operation
304 stainless steel heavy duty rollers with safety device & CNC machining
Patented wheel surface and shape design for effortless movement

Panel Options & Features

Available thicknesses: 68mm, 89mm, and 105mm
Wide selection of acoustical and decorative finishes
6061-T6 profile with internal Q235 steel frame for exceptional durability
Top & bottom jack lifting mechanism seal with 800N power
Magnetic seal in concave & convex profile with 40N/m magnetic attraction

Technical Specifications

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Dimensions in mm*	Design Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology Specifications

Weighted sound reduction value: 52/56 dB (Rw) determined per GB/T19889.3-2005
Positive and frictional locking of vertical element connections
Convex-concave profile form with magnetic strip attraction force of 40 N/m

* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
