Fireproofing Movable Partition Wall with High Pressure Laminate Board and Dupont POM Roller

Brand Name:	AE
Model Number:	AE85
MOQ:	10 Square Meter
Price:	USD90-108 per square meter
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	1000 SQUARE METER PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO9001 SGS CANS

Series:

Movable Partition Wall

Panel Material:

High Pressure Laminate Board

Compliance:

Exhibition Hall, Banquet Hall

Thickness、:

89CM

STC Rating:

42-56dB

Dimensions:

Customization (Height: Up To 6M, Width Per Panel: Up To 1.2M)

Name:

Movable Partition Wall

Packaging Details:

foam layer and hard cardboard with plywood case or steel pallet

Highlight:

High Pressure Laminate Board Movable Partition Wall

Dupont POM Roller Movable Partition Wall

Top & Bottom Jack Lifting Mechanism Movable Partition Wall

Product Description

Fireproofing Movable Partition Walls Operable Partition Panel with Acoustical Fabric

AE Partition provides smart solutions for efficient room management worldwide. Our movable partition walls allow flexible space configuration, adapting any area from small conference rooms to large exhibition halls to accommodate varying user needs.

Key Features and Services:

Dedicated design team for new product development
SGS & ILAC-MRA certified product performance
German partition technology and global professional space solutions
Responsive quotation service

Roller Options & Features:

Dupont POM rollers for smooth operation
304 stainless steel heavy duty rollers with safety device and CNC machining
Patented wheel design for easy partition movement

Panel Options & Features:

Available thicknesses: 68mm, 89mm, and 105mm
Wide selection of acoustical and decorative finishes
6061-T6 profile with Q235 steel frame for enhanced durability
Top & bottom jack lifting mechanism with 800N power
Magnetic seal with 40N/m attraction in concave & convex profiles

Technical Specifications:

Series	Element Thickness (mm)	Element Width (mm)*	Clear Height (mm)*	Construction	Panel Fixing	Vertical Profile Design
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
