Sliding Movable Partition Wall with Dupont POM Roller Magnetic Seal and Jack Lifting Mechanism

Brand Name:	AE
Model Number:	AE65
MOQ:	10 Square Meter
Price:	USD 79-108 per square meter
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	1000 SQUARE METER PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO9001 SGS CANS

Model:

Movable Partition Wall

Finishing Option:

Fireproof Board

Compliance:

Meeting Room, School

Thickness:

68CM

STC Rating:

42-56dB

Dimensions:

Customization (Height: Up To 4.5M, Width Per Panel: Up To 1.2M)

Name:

Movable Partition Wall

Packaging Details:

foam layer and hard cardboard with plywood case or steel pallet

Highlight:

Dupont POM Roller Movable Partition Wall

Magnetic Seal Sliding Partition Wall

Jack Lifting Mechanism Operable Wall Panel

Product Description

Sliding Movable Partition Wall With Soundproofing Panels for School

Movable partition walls are versatile systems designed to create flexible space division in commercial and residential environments.

Quality Service

The performance of the product is certified by SGS & ILAC-MRA
German Partition Technology & Global Professional Space Solutions
Increase the Longevity of Your Specialty Products
Quick follow up with quote
Site inspections
On time deliveries

Roller Option & Features

Dupont POM roller
304 stainless steel heavy duty roller with safety device & CNC machining
Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Options & Features

Thickness: 68mm & 89mm & 105mm
Wide variety of acoustical and decorative finishes available
6061-T6 profile and inside Q235 steel frame for superior durability
Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m

Specifications

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS
Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m

* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
