Aluminum Frame Glass Partition
Created with Pixso.

Sound Proof Glass Partition Wall , Frameless Glass Office Walls 108mm 90mm Thickness

Sound Proof Glass Partition Wall , Frameless Glass Office Walls 108mm 90mm Thickness

Brand Name: AE
Model Number: Panoramic system EGG-100C
MOQ: 10 Square Meter
Price: USD69-92Per Square Meter
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SQUARE METER PER MONTH
Detail Information
Place of Origin:
Guangdong, CHINA
Certification:
ISO9001 SGS
Product Name:
Soudproof Glass Partition System
Application:
Office, Shop
Production Standard:
Basis On The Shop Drawings Which Approved By The Buyer
Profile Of Hanging Partition:
Aluminum Alloy, PVC Strip Sound Proof Partition Walls
Glass Of Hanging Partition:
Clear Tempered Glass, Frosted Glass, Acid Etched Glass
Design:
OEM & ODM
Sound Insulation:
30-42dB
Packaging Details:
foam layer and hard cardboard with plywood case
Highlight:

Soudproof Frameless Glass Office Walls

,

Frameless Glass Office Walls 108mm

,

Sound Proof Glass Partition Wall

Product Description

Soudproof Frameless Aluminum Frame Glass Partition Wall For Office


Discover the perfect blend of style and functionality with our soundproof frameless aluminum frame glass partition walls, designed specifically for office environments. These partitions offer a modern, sleek appearance with their frameless glass panels, enhancing the open feel of your workspace while providing a high level of sound insulation. Ideal for creating quiet, focused areas within your office, they ensure effective noise control without sacrificing elegance. Experience the ultimate in both visual appeal and acoustic performance, and transform your office into a sophisticated, serene environment.


Operation :

Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed , the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.


Specification:



Technical characieristics

WALL THICKNESS
108mm/90mm
HEIGHT up to 3000mm
GRID WIDTH up to 1200mm
WEIGHT 70-80kg/sq.m
ATTACHMENT TO BUILDING STRUCTURE Concealed connections to the slab and walls; sealing along the perimeter; deviations ±10mm in height and width
GLASS THICKNESS 10mm/12mm tempered
VISIBILITY Transparent, coloured, matte glass; between-the-glass blinds; foil, screen printing, enamel
DESCRIPTION Glazed partition with an in-plane streamlined look. Made from aluminium, double-glazing structurally adhered to the profiles.



Project:



Sound Proof Glass Partition Wall , Frameless Glass Office Walls 108mm 90mm Thickness 0Sound Proof Glass Partition Wall , Frameless Glass Office Walls 108mm 90mm Thickness 1
